Hook Suspension Type Pneumatic Hoist with 25 Kg Capacity and Emergency Stop Safety Features
| Brand Name | Juling |
|---|---|
| Certification | CE,API |
| Model Number | DQH Series |
| Minimum Order Quantity | 1 |
| Price | Negotiable |
| Delivery Time | 30 |
| Payment Terms | T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Certifications | CE, ISO9001 | Power Source | Compressed Air |
|---|---|---|---|
| Lifting Height | 3m | Control Method | Pendant Control |
| Color | Yellow Orange Or Other Colors | Usage | Lifting In Oilfield |
| Capacity | 500kg | Air Consumption | 0.8m³/min |
Product Description
Product Description:
The Pneumatic Hoist is a cutting-edge lifting solution designed for industrial applications, featuring an avant-garde design and a compact structure. This hoist is constructed using high-quality alloy steel for the chain material, ensuring durability and reliability in lifting operations.
With certifications including CE and ISO9001, this pneumatic hoist meets international standards for quality and safety. It is optimized for use in oilfields, offering a reliable and efficient solution for lifting tasks in this demanding environment.
Weighing just 25 Kg, this pneumatic hoist is lightweight and easy to handle, making it suitable for various lifting applications. The hoist operates using air pressure in the range of 0.6-0.8MPa, providing sufficient power to lift heavy loads with ease.
The pneumatic hoist is designed to operate within a wide range of ambient temperatures, from -20℃ to 70 ℃, ensuring versatility and adaptability in different working conditions. Whether in extreme cold or heat, this hoist is built to perform reliably and consistently.
Features:
- Product Name: Pneumatic Hoist
- Color: Yellow Orange Or Other Colors
- Air Pressure: 0.6-0.8MPa
- Usage: Lifting In Oilfield
- Capacity: 500kg
- Chain Material: Alloy Steel
Avant-garde design, compact structure, the use of ambient temperature: -20℃ - 70 ℃, not sensitive to dust and humidity
Technical Parameters:
|
Model |
Payload
Capacity(Kg) |
Lifting
Height(m) |
Hoisting
Speed(m/min) |
Lowering
Speed(m/min) |
Rated Air
Pressure(MPa) |
Air
Consumption(m3/min) |
Overall
Dimension(mm) |
Number
Of Chains |
|
QDH0.5 |
500 |
0-10 |
19 |
17 |
0.6 |
1.2 |
300-180-450 |
1 |
|
QDH1.0S |
1000 |
0-10 |
10 |
8 |
0.6 |
1.5 |
300-200-450 |
2 |
|
QDH1.0D |
1000 |
0-10 |
15 |
12 |
0.6 |
1.5 |
300-200-450 |
1 |
|
QDH2.0 |
2000 |
0-10 |
5.5 |
5.5 |
0.6 |
1.2 |
300-200-500 |
2 |
|
QDH3.0 |
3000 |
0-10 |
10 |
11 |
0.6 |
5.5 |
500-240-600 |
1 |
|
QDH5.0 |
5000 |
0-10 |
5 |
5.5 |
0.6 |
5.5 |
500-240-675 |
2 |
|
QDH8.0 |
8000 |
0-10 |
3.2 |
3.4 |
0.6 |
5.5 |
500-240-675 |
2 |
|
QDH10.0 |
10000 |
0-10 |
3.2 |
3.4 |
0.6 |
5.5 |
575-300-820 |
2 |
|
QDH15.0 |
15000 |
0-10 |
2 |
2.1 |
0.6 |
5.5 |
685-310-900 |
3 |
|
QDH20.0 |
20000 |
0-10 |
1.4 |
1.6 |
0.6 |
5.5 |
695-315-1030 |
4 |
|
QDH25.0 |
25000 |
0-10 |
2.4 |
2.8 |
0.6 |
6.5 |
900-445-1260 |
6 |
|
QDH30.0 |
30000 |
0-10 |
2.4 |
2.8 |
0.6 |
6.5 |
900-445-1260 |
6 |
|
QDH40.0 |
40000 |
0-10 |
1.7 |
2 |
0.6 |
6.5 |
1080-450-1470 |
6 |
|
QDH50.0 |
50000 |
0-10 |
1.3 |
1.6 |
0.6 |
6.5 |
1080-430-1485 |
6 |
|
QDH100.0 |
100000 |
0-10 |
1 |
0.95 |
0.6 |
7.5 |
1535-600-1930 |
6 |
Applications:
1. Industrial Workshops: The Pneumatic Hoist is ideal for lifting and moving heavy loads in industrial workshops. Its 500kg capacity, along with safety features such as Overload Protection and Emergency Stop, allows for safe and efficient operations. The Alloy Steel chain material ensures durability and reliability even in demanding industrial environments.
2. Construction Sites: The DQH Series Pneumatic Hoist is well-suited for construction sites where lifting heavy materials is a common task. The hoist's robust construction and reliable performance make it a valuable asset for lifting operations on construction projects.
3. Warehouses: In warehouse settings, the Pneumatic Hoist can be used for lifting and moving goods with precision and ease. Its not sensitive to dust and humidity feature ensures that it can operate efficiently in warehouse environments where dust and humidity levels may be higher.
4. Manufacturing Plants: The Pneumatic Hoist is a valuable tool in manufacturing plants for lifting machinery, equipment, and raw materials. Its efficient air consumption rate of 0.8m³/min makes it cost-effective to operate in manufacturing settings.
5. Maintenance and Repair Work: The DQH Series Pneumatic Hoist is perfect for maintenance and repair work where lifting heavy components is required. Its compact size, lightweight design (25 Kg), and easy maneuverability make it a practical choice for various maintenance tasks.
With its CE and API certifications, customers can trust the quality and safety standards of the Juling Pneumatic Hoist DQH Series. The minimum order quantity of 1, negotiable price, and fast delivery time of 30 days make it a convenient choice for businesses looking to enhance their lifting capabilities.
Overall, the Juling Pneumatic Hoist DQH Series stands out for its versatility, safety features, and reliability, making it a valuable asset in a variety of industrial and commercial settings.
